RemotePro CR – Wiegand-Output Proximity Card Reader – Surface Mount – HID

Model 40-006

This is an HID ProxPoint proximity card reader.

SKU: 40-006 Category:

Description

Security Brands, Inc. offers the RemotePro CR line of 26-bit Wiegand output card readers, available in post or surface mount.

The RemotePro CR series is designed to operate in conjunction with our Advantage DG as well as many popular security management systems using a 26-bit Wiegand protocol. Simply connect the RemotePro CR of your choice to a new or existing master controller (via 6-conductor, 22-gauge wire) and you have immediate access control.

General Specifications

  • Input: 16.5VAC (transformer included)
  • Output: n/o or n/c contact 1-99 second
  • Operating temperature: -15 to 175 Fahrenheit
  • Dimensions: 6.625h x 5.50w x 4.25d
  • Ship weight: 5 Lbs.
  • Relay Specs
  • DC Load AC Load
  • Contact Rating 1A @ 24V .5A @ 120V
  • Max. switching voltage 150V 220V
  • Max. carrying current 2A 2A
  • Max. switching power 28W 60VA
